Standard Configuration:

- 1 Host

- Wireless probe (with a variety of options at different prices) 1PC

Optional probe:

Convex , linear, microconvex , phased array, Transvaginal , rectal, etc., single or dual head probe

Optional accessories:

Silicone ultrasonic keyboard, trolley, probe puncture rack,  wireless charger  printer, etc

Specification:

- Screen: 15inch LCD

- Image mode: B, B/M, B+Color, B+PDI, B+PW

- Channel of ultrasound circuit board: 32/64(different model probe)

- Dimension: L362×W340×H50mm

- Probe Connect: Wireless connect, freely operation

- Operation system: Windows

- Probe Type: Convex, Microconvex, Linear, Small Linear, Transvaginal, Phased array(coming soon), single head or double(the heads can select two in above type)

- Probe element: 128/192(different model probe)

- Probe frequency and scan depth, angle/width:

   Convex head 3.5MHz/5MHz, 90/160/220/305mm, 60°

   Linear head 7.5MHz/10MHz, 20/40/60/100mm, 40mm

   Small Linear head 10MHz/14MHz, 20/30/40/55mm, 25mm

   Microconvex head 3.5MHz/5MHz, 90/130/160/200mm, 88°

   Transvaginal head 6.5MHz/8MHz, 40/60/80/100mm, 149°

- Image Adjust: BGain, TGC, DYN, Focus, Depth, Harmonic, Denoise, Color Gain, Steer, PRF

- Cineplay: auto and manual, frames can set as 100/200/500/1000

- Puncture assist function: the function of in-plane puncture guide line, out-of-plane puncture guide line, automatic blood vessel measurement.

- Measure: Length, Area, Angle, heart rate, Obstetrics

- Image frame rate: 18 frames/second

- Image save: jpg, avi and DICOM format, store volume 120G

- Weight: 4Kg

- Image and report print: can work with most model ink/laser printer

- Remote diagnosis: can install any remote diagnosis software and work

- Battery working time: Probe built-in battery work 2~5 hours(according to different probe and whether continue scan), Host built-in battery work 2 hours

- Probe battery charge: by USB charge or wireless charge, take 2 hours

Specification:

- Screen: 15inch LCD

- Image mode: B, B/M, B+Color, B+PDI, B+PW

- Channel of ultrasound circuit board: 32/64(different model probe)

- Dimension: L362×W340×H50mm

- Probe Connect: Wireless connect, freely operation

- Operation system: Windows

- Probe Type: Convex, Microconvex, Linear, Small Linear, Transvaginal, Phased array(coming soon), single head or double(the heads can select two in above type)

- Probe element: 128/192(different model probe)

- Probe frequency and scan depth, angle/width:

   Convex head 3.5MHz/5MHz, 90/160/220/305mm, 60°

   Linear head 7.5MHz/10MHz, 20/40/60/100mm, 40mm

   Small Linear head 10MHz/14MHz, 20/30/40/55mm, 25mm

   Microconvex head 3.5MHz/5MHz, 90/130/160/200mm, 88°

   Transvaginal head 6.5MHz/8MHz, 40/60/80/100mm, 149°

- Image Adjust: BGain, TGC, DYN, Focus, Depth, Harmonic, Denoise, Color Gain, Steer, PRF

- Cineplay: auto and manual, frames can set as 100/200/500/1000

- Puncture assist function: the function of in-plane puncture guide line, out-of-plane puncture guide line, automatic blood vessel measurement.

- Measure: Length, Area, Angle, heart rate, Obstetrics

- Image frame rate: 18 frames/second

- Image save: jpg, avi and DICOM format, store volume 120G

- Weight: 4Kg

- Image and report print: can work with most model ink/laser printer

- Remote diagnosis: can install any remote diagnosis software and work

- Battery working time: Probe built-in battery work 2~5 hours(according to different probe and whether continue scan), Host built-in battery work 2 hours

- Probe battery charge: by USB charge or wireless charge, take 2 hours
