Specifications:

Imaging Modes: B, B/B, B/M, M, 4B, C, PDI, PW
Scanning mode: Convex, Linear, Endocavity
Gray scale levels:256
Display:15 ’’ high resolution LCD monitor
Transducer Connector:2 standard
Scanning depth: up to 351mm
Physical channels64
Transducer element128
Dynamic imaging technologies: Digital Beam-forming
Digital Frequency Scan
Dynamic Receiving focusing
Dynamic Receiving apodization
Real-time Dynamic Aperture
Imaging processing:
Pre-processing:8-segment TGC adjustment, Dynamic range (0-100), Frame correlation (0-7), Edge enhancement (0-7), Line density (High/Mid/Low)
Post-processing: Gray scale (0-14), Scan angle up to 150, left/right reverse, up/down reverse
Function:
Zoom: 10 times
Cine loop: up to 6400 frames
HDD 500GB
Software function:
General Measurement: distance, circumference, area, (trace/ellipse), volume, etc.
Calculation package: abdomen, cardiac, gynecology, obstetrics, urology,, small parts (thyroid), etc.
Peripheral Ports:
Two Transducer Ports
Two USB Ports
DVI (to connect to external monitor or projector)
Remote
Video Output
S Video
LAN
Power Input Port
Foot switch
Standard Configuration:
15" high definition LED monitor
Two transducer connectors
Back lit control panel
8-segment TGC
982-frame cine loop
Integrated 500GB Hard disk
Internal lithium Battery Supporting normal diagnosis up to 1.5 hours
Inverted Harmonic Imaging
Pseudo color imaging mode
Annotation library for quick comment
Graph/text report function
DICOM storage SCU
User defined exam settings
User defined parameters capture (Acquire Set)
Intuitive soft key at the bottom of screen, clicking supported
Beam steering for better needle visualization
Patient information management system
Fetal trending--Fetal growth curve graph
Lithotripsy function supported
Biopsy function supported
Support polyembryony measurement up to six
Intuitive context dependent soft key
USB image transfer and software upgrade
Language of UI: Chinese, English
3C6C convex array transducer（2.5/3.5/4.5/H5.0/H6.0MHz）
Options:
3C6C convex array transducer (2.5/3.5/4.5/H5.0/H6.0MHz)
7L4C linear array transducer (6.5/7.5/8.5/H9.0/H10MHz)
6E1C endocavity transducer (5.0/6.5/8.0/H8.0/H9.0MHz)
8L4C high frequency linear probe
6C1C micro convex probe
6I7C rectal linear probe
Needle-guided brackets
Home charger and Cararger
Wireless data transfer function
USB water-resistant footswitch
Mobile trolley
Wheeled transport case
Others:
Net weight: Approx.8.5 kg
Power supply: 100~240VAC, 50Hz/60Hz

Dimensions: 400mm×394mm×172mm
