Specifications:

• Scan mode: Electronic Array, convex with cardiac namely phased array or linear array scanning;

• Frequency:  Micro-Convex probe 5.0/7.0MHz, Linear probe 10/12MHz

• Elements: 128 elements

• Scanning Depth: Micro-Convex 60-160mm, Linear 20-80mm, adjustable

• Field of view: Micro-Convex R20, 88°，Linear L40

• Screen: Smart phone or tablet screen

• Supporting system: iOS, Android, Windows

• Display mode: B, B/M, Color, PDI, PW

• Frame rate: 18f/s

• Gain: 30db-105db

• Dynamic Range: 40/50/60/70/80/90/100/110

• Noise reduction: 0-1-2-3-4

• Image gray scale: 256 level

• Image/Video Storage: Store on mobile phones, Tablet PC

• Measure: distance, area, obstetrics and other;

• Power: by built-in lithium battery, 2800mAh

• Battery working time: 2.5hours

• Size/Net Weight: 156mm×60mm×20mm, 250g
