Specifications:

• Probe Head: R60 Convex+R13 Transvaginal

• Scanning mode: Electronic array

• Display mode: B, B/M, color doppler version with B+Color, B+PDI, B+PW

• Probe element: 128

• Channel of RF circuit board: 32

• Probe frequency and scan depth, head radius/width,

  scan angle(convex): Convex head 3.2MHz/5MHz,  90/160/220/305mm,

  60mm, 60°; Transvaginal head 6MHz/8MHz, 30/60/90/120mm, 13mm, 149°

• Image Adjust: BGain, TGC, DYN, Focus, Depth,  Harmonic, Denoise, Color Gain, Steer, PRF

• Noise reduction: 0-1-2-3-4

• Cineplay: auto and manual, frames can set as 100/200/500/1000

• Puncture assist function: the function of in-plane puncture guide line,

  out-of-plane puncture guide line, automatic blood vessel measurement.

• Gain: 30db-105db

• Dynamic Range: 40/50/60/70/80/90/100/110

• Image/Video Storage: Store on mobile phones, Tablet PC

• Measure: distance, area, obstetrics and other

• Power: by built-in lithium battery, 4200mAh

• Battery working time: 3 hours

• Size: 156mm×60mm×20mm

• Net Weight: 220 g

>>Catalog Download
