-Scanning mode: Electronic array
-Image mode: B, B/M, color, PW, PDI
-Frequency: 3.2MHz/5.0MHz, 6.5/8MHz
-Elements: 128
-Channel: 32
-Scan Depth: 90-305mm, 40-100mm
-Scan angle: R60, R13
-Image Adjust: Gain, DYN, Focus, Depth, Harmonic, Denoise
-Cineplay: auto and manual, frames can set as 100/200/500/1000
-Measure: Length, Area, Angle, Obstetrics
-Image frame rate: 18 frames/cond
-Image save format: jpg, mp4 and DCM
-Battery working time:2 hours
-Noise reduction: 0-1-2-3-4
-Dynamic Range: 40/50/60/70/80/90/100/110
-Puncture assist function: in-plane puncture guide line function, out-of-plane puncture guide function
-Charge: by USB, or optional wireless charger
-Size: 336mm×70mm×20mm
-Length: 300mm
-Gain: 30db-105db
-Wifi type: 802.11g/20MHz/5G/450Mbps
-Working system: Android/iOS
